Multi Colors Flexible Electrical Polyolefin Shrink Sleeve

FOB Reference Price:Get Latest Price
US $0.2-10 / Meters | 200 Meter/Meters Shrink Sleeve (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Volsun
Model Number:
Single wall
Type:
Heat Shrinkable
Material:
PE
color:
black/brown/red/orange/yellow/green/blue/purple/ashy/white etc
Continuous operating temperature:
-60℃-200℃
Certification:
Rohs
Heat shrink ratio:
2:1
Fammability:
VW-1
Usage:
Insulation protection
Property:
Excellent physicochemical and electrical performence
Sample:
Free
Delivery:
Fast Express with competitive price
Supply Ability
Supply Ability:
1000000000 Meter/Meters per Day Shrink Sleeve
Packaging & Delivery
Packaging Details
Standard Carton Box for Shrink Sleeve
Port
Shanghai
Lead Time :
2 weeks

Multi Colors Flexible Electrical Polyolefin Shrink Sleeve



Description



Excelllent quality  single wall sauna oblique feet electric heat tube    is made of radiation cross-linked polyolefin, carries excellent physicochemical and electrical properties. Typical applications include insulation of electrical connections or wire splices, rust and corrosion resistance for soldered joints or connections, mechanical and wiring harness protection and insulation. This product is widely used in automotive, agricultural and household machinery with bent tubing where mechanical protection is required, electronics, life consumables, decoration and lighting, communications, ship, aircraft manufacturing and other fields.



Features



² Meets UL 224, CAN / CSA C22.2 NO198.1 -99

² Heat shrink ratio : 2:1

² Halogen-free , low smoke generation , non-toxic , flexible, non flame retardant

² Min. shrink temperature:70 °C

² Min. full recovery temperature :105 °C

² Continuous operating temperature : -55 °C ~ 105 °C

² Environmental standards :RoHS , IPC/JEDEC-J-STD-709 Class H material

² Standard colors : transparent, black , white , red , yellow , green , blue and other four international

    standard colors. More colors are available upon request.















Technical Data





Property

Typical Data

Test method

Density(g/cm3)

1.16±0.05

ISO 2781

Shore A Hardness

65±5

ISO 868

Tensile strength(MPa)

≥4.0

ISO 37

ISO 1817 B

Tensile strength after being immersed in  solvent(MPa)

≥3.0



Elongation(%)

≥210



Elongation after immersion in solvent(%)

≥100



Tear resistance(MPa)

≥3.5

ASTM D 624





Dimension



ID:0.4mm~80mm

ID tolerances:standard: ±0.1mm,also available: ±0.05mm

Characters and Logos screen printed on the surface upon request
